橄欖油，鱷梨油、棕?cái)R油、椰子油和魚油的提取和澄清；
水果、漿果和蔬菜中提取果汁的澄清（芒果漿黑點的去除；葡萄汁和葡萄酒的澄清）
|
Model |
AVOT-2 |
AVOT-3 |
AVOT-4 |
AVOT-5 |
AVOT-6 |
|
Input Density (Max.) kg/dm3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
|
Input Material Temp. (Max.) ℃ |
100 |
100 |
100 |
100 |
100 |
|
Bowl Rotation speed (Max.) |
5000 |
4000 |
3300 |
3000 |
2800 |
|
G-Force (Max.) |
3493 |
3130 |
2739 |
2716 |
2717 |
|
Bowl Material (Standard configuration) |
AISI 304 |
AISI 304 |
AISI 304 |
AISI 304 |
AISI 304 |
|
Bowl Solids Outlet Protection |
Replaceable Carbide Wear Bushings |
||||
|
Scroll Material (Standard configuration) |
AISI 304 |
AISI 304 |
AISI 304 |
AISI 304 |
AISI 304 |
|
Scroll Blade Protection |
Tungsten Carbide,HRC60-62 |
||||
|
Main Motor Power KW |
11 |
22 |
30 |
45 |
55 |
|
Vice Motor Power KW |
4.0 |
7.5 |
11 |
15 |
22 |
|
Motor Driving Type |
Dual Motor |
Dual Motor |
Dual Motor |
Dual Motor |
Dual Motor |
|
Differential Speed rpm |
5-30 |
5-30 |
5-30 |
5-30 |
5-30 |
|
Differential Type |
Planetary Gear |
Planetary Gear |
Planetary Gear |
Planetary Gear |
Planetary Gear |
|
Length mm (Inches) |
2660 (104.7) |
3460 (136.2) |
4350 (171.2) |
4520 (178) |
5080 (200) |
|
Width mm (Inches) |
580 (22.8) |
920 (36.2) |
1120 (44.1) |
1250 (49.2) |
1795 (70.7) |
|
Height mm (Inches) |
1180 (46.5) |
1167 (45.9) |
1365 (53.7) |
1513 (59.6) |
1288 (50.7) |
|
Net. Weight kg |
1000 |
2500 |
4350 |
6000 |
9000 |
*本公司保留對本上述產品及參數的最終解釋權和修改權，如有變更,恕不另行通知.
